Record PT107 Planer Thicknesser (Click&Collect instore only)

£1,499.00

Out of stock

SKU: PT107 Categories: , ,
Delivery Information

Description

This Planer Thicknesser is perfectly suited to the discerning woodworker who expects professional, reliable performance from a solid and durable machine but doesn’t have the space or budget for a larger industrial machine.
Heavy duty cast iron tables give this machine a degree of accuracy not found elsewhere on machines of this capacity or price bracket – infeed table is easily and accurately adjusted using the robust lever and clear depth scale. In addition, the PT107 also boasts an outfeed table adjustment facility, meaning truly exact calibration can be achieved to ensure superior accuracy when planing.
For easy, rapid conversion to thicknessing mode, the hood is a large, steel one-piece swinging design. The thicknessing table is supported by a substantial central column, giving plenty of support to even the heaviest workpieces. To aid the thicknessing of particularly difficult stock, a clutch is provided on the thicknessing feed to allow removal of stock if jamming occurs. This also means that the thicknesser can be disengaged when not in use to save wear and tear on internal parts.

Thicknesser Feed Rate:5 Metres / Minute

Cutter Block Knives:3

Cutter Block Diameter:75 mm

Maximum Thicknessing Height:190 mm

Maximum Thicknessing Width:265 mm

Maximum Thicknesser Depth of Cut:2 mm

Maximum Planing Width:265 mm

Maximum Planer Depth of Cut:3 mm

Planing Table Length:1110 mm

Motor input P1:2.2 kW

Motor output P2:1.69 kW

Weight:162 kg

Size:H950 x W710 x D 1110 mm

Tilting Fence:Tilting Fence

Cast Iron Tables:Cast Iron Tables

Swing Away Table:Swing Away Table

Rubber Out-Feed Rollers :Rubber Out-Feed Rollers

Central Thicknessing Column:Central Thicknessing Column

Independent In & Out Feed Table Adjustment:Independent In & Out Feed Table Adjustment

Wheel Kit Included:Wheel Kit Included
